48v Household Energy Storage System Solar Energy Storage Lifepo4 Battery Pack

Ask Lasest Price
Brand Name :	FBC
Model Number :	FBC-HSO1
Certification :	CE/RoHS/UN38.3/MSDS/ISO
Price :	$2,325.00/sets 2-9 sets
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	10000 units/month
Delivery Time :	7~28work days

Add to Cart

Product Details
Company Profile

48v Household Energy Storage System Solar Energy Storage Lifepo4 Battery Pack

Household Energy Storage System 48v Solar Energy Storage Lifepo4 Battery Pack

Stacked inverter for easy installation and use

Stackable batteries for easy expansion according to demand

Built-in BMS to protect the safety of the battery when in use

Support multiple types of OEM/ODM customization services

Performance parameters
output power	10KW	15KW	20KW	25 KW
Phase	Simplex	Simplex	Simplex	Simplex
maximum output power	3KW/4KW/5KW optional	3KW-5KW optional	3KW-5KW optional	3KW-5KW optional
Rated voltage	51.2V	51.2V	51.2V	51.2V
Rated Capacity	200AH	300AH	400AH	500AH
Continuous discharge current	100A	100A	100A	100A
Peak maximum discharge current	110A/10S	110A/10S	110A/10S	110A/10S
Standard charging current	50A	50A	50A	50A
Fast charge current	100A	100A	100A	100A
Number of expandable batteries	2~15	3-15	4-15	5-15
Optional capacity range	10.24~76.8KWH	15.36-76.8KWH	20.48-76.8KWH	25.6-76.8KWH
cooling method	self-cooling	self-cooling	self-cooling	self-cooling
Battery Type	Lithium Iron Phosphate	Lithium Iron Phosphate	Lithium Iron Phosphate	Lithium Iron Phosphate
design life	＞15 years@25℃	＞15 years@25℃	＞15 years@25℃	＞15 years@25℃
cycle life	≈10000 times	≈10000 times	≈10000 times	≈10000 times
≈10000 times	50HZ/60HZ auto detect	50HZ/60HZ auto detect	50HZ/60HZ auto detect	50HZ/60HZ auto detect
Grid voltage range	230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2%	230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2%	230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2%	230V(170Vac~280Vac) ±2% 110V(90Vac-280Vac)±2%
PV maximum input power	4200W	4200W	4200W	4200W
MPPT voltage range	60-115Vdc	60-115Vdc	60-115Vdc	60-115Vdc
The charging and discharging efficiency of the whole machine	>92%	>92%	>92%	>92%
Battery voltage range	40.0Vdc~60Vdc ± 0.6Vdc (under voltage alarm / shutdown voltage / over voltage alarm / over voltage recovery... LCD screen can be set)	40.0Vdc~60Vdc ± 0.6Vdc (under voltage alarm / shutdown voltage / over voltage alarm / over voltage recovery... LCD screen can be set)	40.0Vdc~60Vdc ± 0.6Vdc (under voltage alarm / shutdown voltage / over voltage alarm / over voltage recovery... LCD screen can be set)	40.0Vdc~60Vdc ± 0.6Vdc (under voltage alarm / shutdown voltage / over voltage alarm / over voltage recovery... LCD screen can be set)
Warranty	Battery (10 years) Inverter (5 years)	Battery (10 years) Inverter (5 years)	Battery (10 years) Inverter (5 years)	Battery (10 years) Inverter (5 years)
Inverter size/weight	602403319mm/15KG	602403139mm/15KG	602403139mm/15KG	602403139mm/ 15KG
Inverter size/weight	602403319mm/15KG	602403139mm/15KG	602403139mm/15KG	602403139mm/ 15KG
Battery size/weight	602403200mm/ 55KG(single layer)	602403200mm/55KG(single layer)	602403200mm/55KG(single layer)	602403200mm/ 55KG(single layer)
Chassis size/weight	60240382mm/60KG	60240382mm/60KG	60240382mm/60KG	60240382mm/60KG
Installation method	Stacked	Stacked	Stacked	Stacked
Certified Specifications
certified product	CE, UN38.3, MSDS, Shipping, Dangerous Package
Cell certification	CE,UL,IEC 62109-1&-2, IEC 62477,EN61000,UN38.3

The battery is compatible with many brands of inverters
